EX2.2 USER GUIDE P. 10
EX2.2 SPECIFICATIONS
Product Number
KVV 987 135 - EX2.2 250V
KVV 987 013 - EX2.2 230V
KVV 987 014 - EX2.2 115V
System Acoustic Perfomance
Max SPL Long-term 130dB
Max SPL Peak 133dB
-3dB Response 45Hz ÷ 125Hz
-10dB Response 40Hz ÷ 125Hz
Crossover Point 125Hz
Low Frequency Section
Acoustic Design Twin Asymmetrical loading
Number of Drivers 2
Woofer Size / Voice Coil Diameter / Design 12" / 3" / Inside outside
Diaphragm Material Epoxy Reinforced Cellulose
Magnet Type Neodymium
Low Frequency Amplifier Specification
Type High efficiency, Current-enhancing switch mode
Rated Continuous Power 1000W
Distortion <0.05%
Operating Bandwidth 40Hz ÷ 125Hz
Signal Input
Input Channels
2
Input Sensitivity 1.0V RMS
Input Impedance 20kΩ (balanced)
Signal Output
Output channels Mid/High, Through
Features
Level Control -6 - +6dB
Phase 0° / 180°
RMS Limiter YES
Power
Power Connector Neutrik PowerCon®
Operating Voltage 115V / 230V / 250V
Operating Voltage Range 100÷120V@60Hz | 205÷240V@50Hz | 225÷260V@50Hz
Recommended Amperage 10A 115V | 5A 230V | 5A 250V
Cooling Passive
Cabinet
Cabinet Material Baltic birch
Handles 2
Pole Mount M20
Color "Orange peeled" Matt Black or any RAL
Physical Dimensions
Height 491mm (19.33")
Width 596mm (23.46")
Depth 616mm (24.25")
Weight 49kg (107.8lbs)
