Page 6

Cascading OmniViews
OmniViews can be cascaded for control over more than 2 computers. The table below shows how many
computers can be controlled from one keyboard, mouse and monitor using OmniView PS/2 2-port units.
Number of
Number of
OmniViews
Computers
1
2
2
3
3
4
4
5
5
6
6
7
7
8
When OmniViews are cascaded, they should follow a tree configuration, not having more than three levels
deep. The console (keyboard, mouse and monitor) is connected to the singular, top-level OmniView. See
the figure below for more information:
NOTE: OmniViews on the second and third level must have all their DIP switches set to OFF.
