ESD12 Specifications:
System Acoustic Perfomance
Max SPL Long-term 127dB
Max SPL Peak 130dB
-3dB Response 55Hz - 22kHz
Recommended Power 500W
Sensitivity 98dB
Impedance 4Ω
Crossover Point 1.2kHz
High Frequency Section
Acoustic Design Horn Loaded
High Horn Coverage Horizontal / Vertical 80° x 40°
Rotatable Horn YES
Throat Exit Diameter / Diaphragm Size 1" / 3"
Diaphragm Material Nitride Titanium
Magnet Type Neodymium
Protection RMS Limiter
Low Frequency Section
Acoustic Design Front Loaded, Bass Reflex
Woofer Size / Voice Coil Diameter / Design 12" / 2.5" / Trans Coil
Diaphragm Material Epoxy Reinforced Cellulose
Magnet Type Neodymium
Protection Thermal breaker - autoreset
Speaker Input
Speaker Input 2x Neutrik Speakon®, Terminal Block
Cabinet
Cabinet Material Baltic birch
Handles 1
Pole Mount 35mm
Color "Orange peeled" Matt Black or any RAL
Physical Dimensions ESD12
Height 606mm (23.86”)
Width 368mm (14.48")
Depth 368mm (14.48")
Weight 23kg (50.7lbs.)
ESD12
Specifications
Specifications
19
