MINIMUM CROSS SECTION
RECOMMENDED SPEAKER CABLE LENGTHS
2.5
2 x 2.5
4
LENGTH, IMPEDANCE 4Ω LENGTH, IMPEDANCE 8Ω LENGTH, IMPEDANCE 16Ω
15
20
30
40
1.5 8 15 30
60
90
25 50 100
ESD, Speakon NL4 wiring
positive pin
(1 +, 2 + parallel)
negative pin
(1 -, 2 - parallel)
1m - round flexible speaker cable,
cross section 2 x 1.5mm
KVV 987 250
PART NUMBER:
PART NAME:
SPEAKON NL4
KVV 987 240
PART NUMBER:
PART NAME:
1m - round flexible speaker cable,
cross section 4 x 2.5mm
KVV 987 251
PART NUMBER:
PART NAME:
SPEAKER CABLES
COVER ESM26
KVV 987 281
PART NUMBER:
PART NAME:
COVER ESM12L
KVV 987 262
PART NUMBER:
PART NAME:
COVERS
COVER ESM12R
KVV 987 261
PART NUMBER:
PART NAME:
10
Accessories
ESM S
eries
Accessories
