Bowers & Wilkins WM 2 User Manual

Page 14

Description

Drive units

Frequency range

Frequency response

Dispersion

Sensitivity

Harmonic distortion

Nominal impedance

Crossover frequency

Power handling

Max. recommended

cable impedance

Dimensions

Net Weight

2-way vented-box system

1x ø25mm (1 in) high frequency
1x ø130mm (5 in) woven fibreglass cone bass/midrange

-6dB at 60Hz and 22kHz

72Hz – 20kHz ±3dB on reference axis

Within 2dB of response on reference axis
Horizontal: over 40º arc
Vertical:

over 10º arc

87dB spl (2.83V, 1m)

2nd and 3rd harmonics (90dB, 1m)
<1% 95Hz – 20kHz

8Ω (minimum 3.0Ω)

3.5kHz

25W – 90W into 8Ω on unclipped programme

0.2Ω

Height: 230mm (9.0in)
Width: 162mm (6.4in)
Depth: 187mm (7.4in)

3kg (6.6lb)

WM 2

Issue

B&W Loudspeakers Ltd. reserves the right to amend details of the specification without notice in line with technical developments. E&OE
