5
Specifications
* Half-Space Response, 16-ohm input
† Front panel, switch-selected.
SPECIFICATIONS HFSF1
Frequency Response (-10 dB)* 78 Hz to 20 kHz
LF Driver 4" Polypropylene Cone
HF Driver 3/4" Polycarbonate Dome
Sensitivity (1W/1m)* 86 dBspl
Dispersion 150 degrees
Power Input (Max.) 50W @ 16 ohms; 16W @ 70V
Power Settings (in watts)† 70V: 16, 8, 4, 2, 1
Baffle Material Fire-rated (94V0) ABS
Back Can Material Heavy-Gauge Steel
Terminations 4-Terminal Snap-Lock Input Connector
Included Accessories (1) Snap-Lock Input Connector, (1) Steel Terminal Cover
with (2) mounting screws
Minimum Vertical Clearance 7-1/8" (From front of mounting surface)
Ceiling Cutout 6-1/4" dia.
Shipping Weight 5 lb.
Speaker Dimensions 7-1/4" dia. x 7-1/2" D
