Briggs & Stratton PowerBoss 030217 - Manual (Page 3)

5250W Portable Generator
3
EXPLODED VIEW - PARTS LIST
Item Part # Description
1 B195681GS CRADLE
2 194150GS KIT, Mount,Vibration, 45°
3 * NUT, M4 - 0.7
4 194364GS ADAPTER, Engine
5 194623GS KIT, Grounding Hardware
6 194151GS KIT, Hardware Mounting, Alt
7 * WASHER, #8 Lock
8 96796GS WASHER, M8 Flat
9 * WASHER, M4 Flat
10 190274BGS SBHCS, 3/8-16 x 3/4 Lg.
11 45757GS HHCS, M6 - 1.0 x 25
12 43437GS OUTLET, 120/240V, 30A
13 194608GS KIT, Alt Support w/ Hardware
14 68759GS OUTLET, 120V, 20A, Duplex
15 194584GS KIT, Hardware Terminal Box
16 * WASHER, Shakeproof, Int. #8
17 697252 MUFFLER
18 194366GS CAP
19 392390 SPARK ARRESTER, w/ Screws
20 B4986GS DECAL, Ground, Green
21 194153GS KIT,Vibration
22 697255 GASKET, Exhaust
23 194154GS KIT, Grounding Hardware
24 * SCREW, PH M4 x 12
25 75207GS BREAKER, Circuit, 20A
26 695400 TAB, Locking
27 695399 SCREW, Shoulder
28 695312 SCREW
31 191436GS DECAL, Hot Muffler
Item Part # Description
32 * HHCS, 5/16" x 3/4" SEMS
33 B4260GS DISK, Air Blocker
34 194587GS TERMINAL BOX, with Hardware
35 194265GS KIT, Fuel Hose w/Clamps
40 194398GS KIT, Hardware Fuel Tank
41 192980GS KIT,Valve, Fuel
44 194217GS ASSY,Tank, Fuel (Includes Items 41,
50, 51 & 52)
45 90878GS CAP, Fuel
48 194622GS WIRE, Ground Mount
50 188333GS DECAL, Gas Fill
51 194799GS DECAL, Danger
52 189235GS DECAL, Start Instructions
54 194448GS KIT, Insulation with Clip
55 191435GS DECAL, Fuel Shut-off
60 193452GS SHIELD, Heat
900 § ENGINE
Parts Not Illustrated
195679GS MANUAL, Owners
MS5242 MANUAL, Engine
BB3061BGS BOTTLE, Oil
196790GS KIT, Decal Service
189208GS FUEL STABILIZER
* - Items without part numbers are common fasteners and
are available at your local hardware store.
§ - Contact Engine Manufacturer
