XENYX X1622USB Recording Setup
DI100
XENYX X1622USB
Acoustic
Guitar
Electric
Guitar
USB In/Out
Drum Machine
Keyboard
HPS3000
B3031A Active
Studio Monitors
CTRL Out L
CTRL Out R
Laptop
B-2 PRO
X1622USB Rear Panel
IEC power
socket
Power
switch
Phantom Power
switch
USB/Audio
Interface port
Main Outputs,
XLR balanced
Sub 1 & 2
Outputs, ¼" TS
unbalanced
Control Room
Out, ¼" TS
unbalanced
Channel 1-4
Inserts
