MODEL 37610701 - 04 PeCo
ASSEMBLY
STEP 5:
Attach Base Frame (A) to Mount Plate (C) and secure by dropping in ball pin
(#J0248). With hood open on the Base Frame (A) insert the 7cu. ft. Canister
(B) and close
STEP 6:
Place Clamps (A) over each end of
6" Hose (B). Attach one end of hose
onto Blower Housing (C). Attach free
end of hose over Inlet (D).
TIGHTEN CLAMPS!
C
B
A
REAR VIEW OF MOWER
A
D
B
C
8
