ADJUSTING THE OPTICAL VIEW
The distance between the eyes varies from
one person to the next. To achieve perfect
alignment of the eyes and the lens openings,
hold the binocular in the normal viewing
position and move the two barrels either
apart or closer to each other until you have
a single, clear field of view.
FOCUSING
1. Cover the right front lens with your hand
and rotate the focusing wheel (B) until the
image in the left eye piece appears sharp.
2. Now cover the left front lens with your
hand and rotate the dioptre adjustment
(A) until the image is sharp.
3. The binoculars have now been adjusted
to your eyes.
A. Diopter Adjustment
B. Focusing Wheel
C. Twist-Up Eyecups
Diopter
Lock/Unlock
