General Machine Products Co. Inc. • 3111 Old Lincoln Highway, Trevose, PA 19053 USA • 215.357.5500 • 215.357.6216 (Fax) • [email protected] • www GMPtools.com
Modular Plug Presser
GMP Plug & Die Compatibility
GMP Modular Plugs
GMP Presser Dies
P/N Description
17064
4
17065
6
17066
8
17097
B8
25547
S8
17100
10
Tinsel & Stranded Wire
17074 4x4 (4P4C) Handset 100/pkg.
Y
N N N N N
17078 2x6 (6P2C) Line Cord 100/pkg.
N
Y
N N N N
17075 4x6 (6P4C) Line Cord 100/pkg.
N
Y
N N N N
17076 6x6 (6P6C) Line Cord 100/pkg.
N
Y
N N N N
17077 8x8 (8P8C) Line Cord 100/pkg.
N
N
Y
N N N
17043 8x8 (8P8C) Keyed Right Line Cord 100/pkg.
N
N
Y
N N N
25127 10x10 (10P10C) Non-Keyed Line Cord 25/pkg.
N
N
N
N
N
Y
25125 10x10 (10P10C) Keyed Left Line Cord 25/pkg.
N
N
N
N
N
Y
25126 10x10 (10P10C) Keyed Right Line Cord 25/pkg.
N
N
N
N
N
Y
Solid Wire
24061 3-Pair .038 in. Dia. (6P6C) (Gray Tint) 100/pkg.
N
Y
N N N N
24062 4-Pair .038 in. Dia. (8P8C) (Gray Tint) 100/pkg.
N
N
Y
Y
N N
17188 4-Pair .033 in. Dia. (8P8C) (Blue Tint) 100/pkg.
N
N
Y
Y
N N
24042 4-Pair Shielded Twisted Pair 8x8 (8P8C) 25/pkg.
N
N
N
N
Y
N
24065 4-Pair UTP Cat 6 Cable .042 in. Dia. Wire (8P8C)
1
100/pkg.
N N N
Y
N N
17090 DEC Data Cable /DEC MMP 6x6 (6P6C) 100/pkg.
N
**
N N N N
Y=Yes N=No
1
Supplied with Alignment Bar ** Requires DEC compatible presser; contact us for modification information
Dies for AMP
®
Plugs
P/N Die # Description
25943
A6
For AMP 6 Position Modular Plugs
17095
A8
For AMP 8 Position Modular Plugs
17126
A6S
For AMP 6 Position Shielded Modular Plugs
P/N 17074 - 4x4 (4P4C)
P/N 17078 - 2x6 (6P2C)
P/N 17075 - 4x6 (6P4C)
P/N 17076 - 6x6 (6P6C)
P/N 17043 Keyed Right - 8x8 (8P8C)
P/N 17077 8x8 (8P8C)
P/N 25127 - 10x10 (10P10C)
P/N 25125 Keyed Left -10x10 (10P10C)
P/N 25126 Keyed Right -10x10 (10P10C)
P/N 24061 3 Pair .038 - 6x6 (6P6C) (Gray)
P/N 24062 4 Pair .038-8x8 (8P8C) (Gray)
P/N 17188 4 Pair .033 8x8 (8P8C) (Blue)
P/N 24042 4 Pair Shielded Twisted Pair
8x8 (8P8C)
P/N 24065 4 Pair UTP Cat 6 Cable .042 Dia
8x8 (8P8C) With Alignment Bar
P/N 17090 DEC Data Cable /DEC MMP
6x6 (6P6C)
7/12/2011 AK
L to R: 25127 (clear), 24062 (gray), 17188 (blue), 24042 (shielded)
Modular Plugs & Dies
