RD7000 Operation Manual 11
3.14 Transmitter power output
The transmitter supports several power output modes to
help you select the optimal settings for your requirements
whilst helping to prolong battery life.
3.14.1 Adjusting power output
To adjust the power output:
Switch on the transmitter.
Press the or keys to increase or decrease
power output.
3.14.2 Boost (Tx3 and Tx10 only)
Boost allows the transmitter to output its maximum
wattage for a specified period of time in minutes.
WARNING! The transmitter is capable of
outputting potentially lethal wattages. Exercise
extreme caution when using Boost.
To configure boost:
Switch on the transmitter.
Press the key to enter the menu.
Scroll to the BOOST option using the or
arrows.
Press the key to enter the BOOST menu.
Set the BOOST duration using the or
arrows. You can choose 5, 10, 15 and 20 minute
periods.
Press the key to accept your changes and exit
the BOOST menu.
Press the key to exit the menu.
To enable boost:
First configure the boost duration using the
procedure above.
Press and hold the arrow until BOOST
appears on the transmitter LCD.
The transmitter will automatically exit boost mode
after the allotted duration.
To disable boost
Press and hold the arrow to switch boost off.
