22

23

Fractal Design

Newton Series

Power Specification

Power supply unit (PSU) specification compliance

ATX 2.31 & EPS 2.92

Dimensions (mm)

150*86* 165

Life expectancy (MTBF) at maximum output load

100,000 hours

Power factor correction (PFC)

Active

Fan type

135mm, sleeve / ball bearing

Operating temperature

0-50°C

Operating humidity

10-90%

Protected against

Over power

Over voltage

Short circuit

Efficiency

80 PLUS® Platinum certified

Safety approvals

UL, cUL, TÜV

Electromagnetic compatibility (EMC) standard compliance

CE, FCC, C-tick

Hazardous materials

WEEE/RoHS compliant

600W

800W

1000W

AC Input

Voltage

90-264V AC

Frequency

47-63 Hz

Current (115V/230V)

10A/5A

15A/ 7.5A

DC Output

3.3V

20A

5V

20A

3.3V and 5V combined

100W

12V

50A

66A

80A

-12V

0.5A

5V Standby (+5Vsb)

2.5A

Total Power

600W

800W

1000W

Newton R3 Series Specification

General Specification

Package contents

Newton R3 PSU in protective bag

AC Power cord (localized)

Modular cables in a cable rollout

Velcro cable ties & zip ties

User’s Manual (this book)

Mounting Screw pack

DC Voltage Regulation

Maximum difference between DC output voltage and nominal value under any load,

line and environmental conditions within specification. The following are the maximum

values allowed by Fractal Design quality control; typical values are lower.

Ripple and Noise

Peak-to-peak values of periodic or random signals present on the DC rails over a

frequency band of 10Hz to 20Mhz. The following are the maximum values allowed by

Fractal Design quality control; typical values are lower.

Cable configuration

3.3V

5V

12V

-12V

+5Vsb

ATX Specification

<5%

<5%

<5%

<10%

<5%

Fractal Design Newton R3 Series

<3%

<3%

<3%

<8%

<3%

3.3V

5V

12V

-12V

+5Vsb

ATX Specification

<50 mV <50 mV <120 mV <120 mV

<50 mV

Fractal Design Newton R3 Series <35mV <40mV

<60 mV

<60 mV

<35mV

Connector type

Quantity

Cable type

600W

800W

1000W

ATX 20+4 pins

1

Fixed

ATX12V/EPS12V 4+4 pins

1

Fixed

ATX12V/EPS12V 8 pins

0

1

Modular

PCI-E 6+2 pins

2

4

Fixed

2

Modular

SATA

9

12

Modular

Peripheral

4

Modular

Floppy

1

Modular
