Fractal Design
Tesla Series
Power Specification
Tesla R2 Series Specification
General Specification
Power supply unit (PSU) specification compliance
ATX 2.31
Dimensions (mm)
150*86* 165
Life expectancy (MTBF) at maximum output load
100,000 hours
Power factor correction (PFC)
Active
Fan type
135mm, sleeve / ball bearing
Operating temperature
0-40°C (50°C at 80% load)
Operating humidity
10-90%
Protected against
Over power
Over voltage
Short circuit
Efficiency
80 PLUS® Gold certified
Safety approvals
UL, cUL, TÜV
Electromagnetic compatibility (EMC) standard compliance CE, FCC, C-tick
Hazardous materials
WEEE/RoHS compliant
500W
650W
800W
1000W
AC Input
Voltage
90-264V AC
Frequency
47-63 Hz
Current
10A/5A
15A/ 7.5A
DC Output
3.3V
20A
5V
20A
3.3V and 5V combined
100W
12V
41.5A
54A
66A
80A
-12V
0.5A
5V Standby (+5Vsb)
2.5A
Total Power
500W
650W
800W
1000W
DC Voltage Regulation
Maximum difference between DC output voltage and nominal value under any load,
line and environmental conditions within specification. The following are the maxi-
mum values allowed by Fractal Design quality control; typical values are lower.
3.3V
5V
12V
-12V
+5Vsb
ATX Specification
<5%
<5%
<5%
<10%
<5%
Fractal Design Tesla R2 Series
<3%
<3%
<3%
<8%
<3%
3.3V
5V
12V
-12V
+5Vsb
ATX Specification
<50 mV <50 mV <120 mV <120 mV <50 mV
Fractal Design Tesla R2 Series
<40mV
<40mV
<70 mV
<60 mV
<40mV
Ripple and Noise
Peak-to-peak values of periodic or random signals present on the DC rails over a frequency
band of 10Hz to 20Mhz. The following are the maximum values allowed by Fractal Design
quality control; typical values are lower.
Connector type
Quantity
500W
650W
800W
1000W
ATX 20+4 pins
1
ATX12V/EPS12V 4+4 pins
1
PCI-E 6+2 pins
2
4
6
SATA
5
6
7
9
Peripheral
2
Floppy
1
Cable configuration
Package contents
Tesla R2 PSU in protective bag
Velcro cable ties & zip ties
User's Manual (this book)
Mounting Screw pack
AC Power cord (localized)
