Node 304

4

The Node 304 is compatible with ATX power supply units (PSU) up to 160mm in length.

PSUs with modular connectors on the back typically need to be shorter than 160 mm when

used in combination with a long graphics card.

Installing graphics cards

The Node 304 was designed with the most powerful components in mind. In order to install

a graphics card, one of the hard drive brackets, located on the same side as the mother-

board’s PCI slot, must first be removed. Once removed, the graphics card can be inserted

onto the motherboard.
The Node 304 is compatible with graphics cards up to 310mm in length, when 1 HDD

bracket is removed. Please note that graphics cards longer than 170 mm will conflict with

PSUs longer than 160mm.

Cleaning the air filters

Filters are installed at air intakes to help prevent dust from entering the case. To ensure

optimal cooling, filters should be cleaned at regular intervals:

To clean the PSU filter, simply slide the filter toward the rear of the case and remove it;

clean any dust gathered on it.

To clean the front filter, first remove the front panel by pulling it straight out and using

the bottom as a handle. Be careful not to damage any cables while doing this. Once

the front panel is off, remove the filter by pushing the two clips on the sides of the filer.

Clean the filters, then reinstall the filter and front panel in reverse order.

By design, the side filter is not removable; the side filter can be cleaned when the top

part of the case is removed.

Fan controller

The fan controller is located at the rear of the case over the PCI slots. The controller has

three settings: low speed (5v), medium speed (7v) and full speed (12v).

Limited warranty and limitations of liability

Fractal Design Node 304 computer cases are guaranteed for twenty four (24) months from

the date of delivery to end-user, against defects in materials and/or workmanship. Within

this limited warranty period, products will either be repaired or replaced at Fractal Design’s

discretion. Warranty claims must be returned to the agent who sold the product, shipping

prepaid.
The warranty does not cover:

Products which have been used for rental purposes, misused, handled carelessly or

applied in such a way that is not in accordance with its stated intended use.

Products damaged from an Act of Nature including, but not limited to, lightning, fire,

flood and earthquake.

Products whose serial number and/or the warranty sticker have been tampered with or

removed.

Product support

For product support, please use the following contact information:

In

North

America:

[email protected]

In DACH (Germany-Switzerland-Austria):

[email protected]

In

China: [email protected]

In Europe and/or Rest of World:

[email protected]
