Functional description and specifications, Rotary hammer – Bosch 11245EVS User Manual
Page 6
-6-
Model number
11245EVS
Shank style
SDS Max
Maximum Capacities:
Carbide tipped bits
2”
Thin wall core bits
6”
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Rotary Hammer
DUST SHIELD
LOCKING SLEEVE
VENTILATION OPENINGS
SELECTOR LEVER
TRIGGER
SWITCH
VARIABLE
SPEED DIAL
SERVICE
REMINDER
LIGHT
VENTILATION
OPENINGS
HAND GRIP
AUXILIARY
HANDLE
FIG. 1
RELEASE BUTTON
NOTE: For tool specifications refer to the nameplate on your tool.
