Baja Marine Sportfish Tournament Edition 230 - Manual (Page 32)

230 Sportfish ® TE 2.4
S
eCtion
2 • g
eneral
B
oat
a
rrangeMent
6. G
eneral
d
eck
l
aYout
GENERAL DECK LAYOUT
(FIG. 2.4.1)
fWD
REaR
(afT)
lEfT
(PORT)
RIghT
(STBD)
Drain
Storage
Grab Rail
Leaning Post
Fuel Fill
Cleat
Storage/Fish Locker
Bow Light
Horn
Cleat
Cleat
Bilge Access
Cleat
Bow Light
Windshield
Cleat
Helm
Inspection Plate
Grab Rail
Storage
Drain
Cleat
Grab Rail
Outdrive
Rod Holders (opt.)
Rod Holders (opt.)
Windlass (opt.)
Baitwell (70 Gal)
Center Console Access
Outboard Oil Fill Access to Live Well
Transom Live Well
