GettinG Started / inStallation tipS

IMPORTANT! read all instructions
carefully and completely to ensure
proper installation.

WARNING! parts have sharp
points & edges. Use extreme
caution when handling & installing.
Wear safety glasses at all times.

®

power screw gun with

ratcheting torque setting

tiger Claw

Slot Cutter

router

Tools & Materials Needed

Safety Glasses

Email: [email protected]
Tech Support: 800-518-3569 toll free
Customer Service: 800-518-3569 toll free
Fax: 413-786-1760

153 Bowles Road • Agawam, MA 01001

INST

ALL

ATION PR

OCESS

For

TC-

G (

TC-150) f

or use with 1" (25mm) or thicker deck

ing

TC-120 f

or use with

3

4

" (19mm) deck

ing

JOIST

a

place next deck board into position against
fasteners. Slightly raise outer edge of board
being installed and slide board onto fastener
until board contacts spacer tabs.

b

Check gap between boards for consistency.
apply force to ensure board is fully installed.

Repeat steps 2 thru 4 until deck is complete.

Step

1

Step

2

Step

3

Step

4

inStall

firSt board

poSition faStenerS

inStall

firSt faStener

CoMpletinG

inStallation of boardS

HOUSE

fasten one edge of the first board at each framing
support using a quality 2½" (64mm) deck screw. it is
important that this board is straight and well secured.

fully insert tC-G or tC-120 fastener into grooved
edge of deck board. Screw hole should line up with
the center of support joist.

While standing on deck board, install provided
screw at 45° angle through fastener and into joist,
while applying pressure on fastener. install one
fastener and screw at each support joist.

Make sure fastener body is vertical to deck
board and the screw is holding fastener down
tight to support joist. adjust torque setting on
screw gun to prevent spin out of the screw head.
