2.4.2 Connecting the Ocarina to the Evaluation Board
Each Ocarina has 35 pins, therefore, great care should be taken aligning its pins with the sockets on
the board when assembling. Push the Ocarina into the Evaluation Board firmly and evenly.
Figure 2-2:
Assembling the Ocarina on the Ocarina Evaluation Board
M2.5X5mm
Spring washers
4 spacers
recommended
M2.5X21mm
Ocarina Evaluation Board User Guide
Evaluation Board Connectors and Cables
MAN-EVLBRD-OCA (Ver. 2.2)
2-6
