Components parts and fittings contained in the box
Please sort out all parts before you begin to assemble the item. This to make sure you always use the correct part.
Fittings
Parts
Hazard Warning !
Keep small components out of the reach of children.
A 29 pcs. Dowel - Ø10 x 40mm
305 / 0003
Page 2 of 8 Colorado bunk bed
C 1 pc. Allen key 4mm
309 / 0002
B 22 pcs. Barrel nut - M6 x 13mm
303 / 0004
D 22 pcs. Bolt - M6 x 110mm
304 / 0060
E 4 pcs. Dowel - Ø12 x 60mm
305 / 0018
F 8 pcs. Screw - Ø3.5 x 35mm
318 / 0001
G 60 pcs. Screw - Ø3.5 x 25mm
318 / 0002
H 7 pcs. Screw - Ø7 x 50mm
308 / 0001
I 6 pcs. Screw - Ø4 x 50mm
302 / 0035
Headboard lower
2 pcs.
219 / 1007
10
07
x
7
8
0
m
m
1
10
07
x
693
m
m
Headboard
upper, left
1 pc.
219 / 1005
2
Headboard
upper, right
1 pc.
219 / 1006
3
Side rail
4 pcs.
114 / 0256
4
1900 x 110mm
Side panel, upper,
long
1 pc.
114 / 1016
5
1900 x 90mm
Side panel, upper,
short
1 pc.
114 / 1017
6
1508 x 90mm
Side panel, lower,
long
1 pc.
114 / 9016
7
1900 x 65mm
Side panel, lower,
short
1 pc.
114 / 9017
8
1508 x 65mm
Slats
26 pcs.
114 / 0194
9
916 x 65mm
Slats, with cut
4 pcs.
114 / 0203
10
916 x 65mm
Distance brick
1 pc.
105 / 0102
11
68 x 68mm
Side left, ladder
1 pc.
220 / 1003
12
11
58
x
5
0
m
m
Side right, ladder
1 pc.
220 / 9003
13
88
0 x
5
0
m
m
3 pcs.
220 / 0014
14
303 x 44mm
Step
ladder
1007
x
6
9
3
m
m
6
