Component parts and fittings contained in the box
PARTS
Fittings
A
B
C
D
E
F
G
H
I
J
K
L
N
M
Locking Nut 16pcs
M8 Barrel Nut 4pcs
M8 x80mm Bolt 4pcs
Φ8 Washer 4pcs
Locking Pin 16pcs
Φ10Dowel 4pcs
Φ8 Dowel 12pcs
1/4″JCN Nut 4pcs
1/4″*3/4″Bolt 4pcs
M8*20 Bolt 10pcs
Nut 2pcs
Spanner 1pc
4MM Allen key 2pc
5MM Allen key 1pc
1 piece
1 piece
2 pieces
1piece
2 pieces
1 piece
2 pieces
2 pieces
2 pieces
