Quick Start Guide
Port Meaning
1
Power Switch
Power ON/OFF switch
2
PWR
Connect the supplied power adapter to this jack.
3 RESET
After the device is powered on, press it to reset the
device or restore to factory default settings.
0-3 seconds: reset the device
6 seconds above: restore to factory default settings (this
is used when you can not login to the router, e.g. forgot
the password)
4
LAN
1X — 3X
(RJ-45 connector)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one
of the four LAN ports when connecting to a PC or an
office/home network of 10Mbps or 100Mbps.
5
CONSOLE
Connect a PS2/RS-232 cable to this port when
connecting to a PC’s RS-232 port (9-pin serial port).
6
Phone
1X ─ 2X
(RJ-11 connector)
Connect RJ-11 cable to this port when connecting to an
analog phone set.
7
ADSL Connect the supplied RJ-11 (“telephone”) cable to this
port when connecting to the ADSL/telephone network.
8
Antenna
(BiPAC 7402VGL/VGP only)
Connect the detachable antenna to this port.
9
LINE
(BiPAC 7402VGP only)
Connect RJ-11 cable to this port when connecting to the
telephone wall jack.
