Compact

Active Speakers

73

MINIBOX

Series

Compact

Active Speakers

Active Speakers

A powerful yet surprisingly light cabinet, the remarkably compact L160D
offers a variety of connection options to provide convenient sound
reinforcement for multimedia applications.

Paired with a DSP, the two 5“ phase-corrected loudspeakers deliver
astonishingly high sound pressure levels for their size and an amazingly
transparent and articulate sonic image.

The multifunctional housing offers wall-mount fixing points for permanent
installation and a pole mount for portable use.


Technical Data

Speaker Type: 2-Way Active Speaker

Acoustical data

Frequency Response [-10dB] 70 - 20.000 Hz
Max SPL: 116 dB
HF: 1 “
Type HF: Dome Tweeter, coaxial
Directivity: 85 x 75 °
LF: 2x 5 “

Amplifier

Amp Technology: digipro®
Amp Class: Class D
Power PRG: 160 W
Cooling: Convection

Processor

Controller: DSP 24bit/48kHz
System Presets: 8
Limiter. Dual Active Peak, RMS, Thermal
Slope MF-HF: 24 dB/Octave

Inputs

Signal Input: 1x XLR Line In/Mic
1x 6.3mm phone jack
1x RCA cinch AUX with volume ctrl
Microphone Input: Yes
Signal Output: 1x 6.3mm phone jack
Power Socket: VDE
Voltage Range: 110-120 - 220-240 V

Mechanics

Housing: Polyporpylen PP
Angles Up: 60° for monitor use °
Rigging Points: 2x M5 on side
2x M5 on bottom for accessories
Accessory: WB03, SN120
Width: 200 mm (8 in)
Height: 335 mm (13.4 in)
Depth: 220 mm (8.8 in)
Weight: 5.2 kg (11.46 lbs)

MINIBOX L160 D

PACK

WB03

WB11
