dB TECHNOLOGIES DVA T12 v2 - Manual (Page 2)

3-Way Active
Line Array Module
Technical Data
Speaker Type: 3-Way Active Line Array Module
Acoustical data
Frequency Response [+/- 3dB]: 60 - 19.000 Hz
Max SPL: One Unit: 136 dB
HF: 3x1 “
Voice Coil HF: 1.4 “
Directivity: 100x10° Single unit
Horn: Integrated CD Horn
MF: 2x 6.5 “
Type MF: Neodymium Sealed Basket Phase
Plug Horn Loaded
Voice Coil MF: 2 “
LF: 12 “
Type LF: Neodymium
Voice Coil LF: 3 “
Amplifier
Amp Technology: Digipro® G2
Amp Class: Class D
HF Amp: 350 W RMS
MF Amp: 350 W RMS
LF Amp: 710 W RMS
Cooling: Convection
Processor
Controller: DSP 56 bit
AD/DA Converter: 24 bit/96 kHz
System Presets: 8, HF/Low-mid correction
Limiter: Dual Active Limiter Multiband RMS,
Peak, Thermal
Crossover Frequency MF-HF: 1800 Hz
Slope MF-HF: 24 dB/Octave
Crossover Frequency LF-MF: 420 Hz
Slope LF-MF: 24 dB/Octave
Input
Signal Input: 1x XLR fem, Bal.
Signal Output: 1x XLR male, Bal.
Network: RDnet remote control RJ45 connector
IN/OUT
Power Socket: 1x Powercon In 1x Powercon Out
Voltage Range: 90 - 240 V
Mechanics
Housing: Polypropylen PP Aluminium reinforced
Housing Design: Trapezoidal 10°
Rain cover: Included
Rigging Points: Integrated rigging hardware
Width: 580 mm (23.2 in)
Height: 386 mm (15.44 in)
Depth: 430 mm (17.2 in)
Weight: 29,9 kg (63.93 lbs)
DVA T12
7
The DVA T12
features state-of-the-art neodymium speakers and
high-performance digital amps with total of 1,410W output power.
In combination with top-drawer DSP and premium quality AD-DA
converter, it delivers high-definition sonic images with massive SPL
for large sound reinforcement applications.
Weighing just 29kg
, this remarkably compact unit belies its
unobtrusive look by enabling you to set up very powerful line arrays
that deliver extraordinary performance.
3-Way Active
Line Array Module
