STEP 5: Grease the inside of the auger collar liberally and attach the auger with the
retaining bolt and nut that came attached to the drive unit spindle. This is a
special thread length bolt - use genuine Danuser replacement parts only. Use
Danuser PN 10038 (3/4” 10 x 4”, Gr. 8, 3/4” of thread) special retaining bolt and
nut PN 10041. NEVER use a bolt longer than longer than 4".
STEP 6: The drive unit is shipped with fittings installed in the motor ports: female #12
JIC fittings on Models 2545H and 3060H and female #12 o-ring face seal fittings
on Models HP-2545H and HP-3060H. Install minimum inside diameter 3/4"
hoses. Since the motor is reversible, hose connections to motor fittings are
interchangeable.
STEP 7: You must obtain and install the proper hydraulic quick couplers for your
particular vehicle.
STEP 8: After you have tightened the drive unit connections, run the hoses through the
hose holder on the quick attach plate (skid-steer mount only) and plug them into
your auxiliary hydraulic outlets.
STEP 9: Test the vehicle to make sure you have enough hose length to perform the full
range of the loader arms’ operating heights.
Remember hydraulic systems are under pressure whenever
the engine is running and may hold pressure after shutdown.
Before connecting or disconnecting hydraulic hoses, be sure
to relieve all pressure by cycling all hydraulic controls after
shutdown.
Never check pressurized system for leaks with your bare
hand. Wear proper hand and eye protection and use wood or
cardboard when searching for suspected leaks. Oil escaping
from pinhole leaks under pressure can penetrate skin and
create a serious medical emergency. If any fluid is injected
into the skin, gangrene, blood poisoning, even death may
result. Obtain medical attention immediately.
Assembly &
Installation
(continued)
Each time an auger or extension is attached to the drive unit, the inside of the
collar should be coated liberally with grease.
All hoses and fittings used to connect the earth auger should be thoroughly
cleaned before use. Care should be taken to see that no thread sealer or metal
chips are forced to the inside of the joints when connections are being tightened.
Fittings must be compatible with the fittings on your vehicle. Be sure the threads
match on the hydraulic quick couplers you are using.
