MX-5 DL Ultrasonic Thickness Gauge
19
The Back light
The back light of the MX-5 DL can be set to three different positions
on/off/auto. The following steps outline the procedure for changing the
settings of the back light:
1) Press ON/OFF key to power up the MX-5 DL.
5) Press the MODE key to activate features and settings.
6) Press the UP / Down arrow keys to scroll to the LItE symbol.
7) Press the SEND key to toggle the status of the back light
on/off/auto.
8) Press the MODE key once again to return to measurement mode.
Scan Mode
While the MX-5 DL excels at making single point measurements, it is
sometimes desirable to examine a larger regio n, searching for the thinnest
point. The MX-5 DL includes a feature, called Scan Mode, which allows it
to do just that.
