13
CHAPTER 3: Configuration and Installation
Position
1
2
3
4
5
6
7
8
Flow Control
Hardware
OFF*
Software
ON
LED
Enabled
ON*
Disabled
OFF
Parity/D. Bits/
S. Bit
None/8/1
OFF
OFF
OFF*
Odd/8/1
ON
OFF
OFF
Even/8/1
OFF
ON
OFF
None/7/2
ON
OFF
ON
Odd/7/2
ON
ON
OFF
Even/7/2
OFF
OFF
ON
Odd/7/1
OFF
ON
ON
Even/7/1
ON
ON
ON
D. Rate (bps)
300
OFF
OFF
ON
600
ON
OFF
ON
1200
ON
ON
OFF
2400
OFF
ON
ON
4800
ON
ON
ON
9600
OFF
OFF
OFF*
19200
ON
OFF
OFF
38400
OFF
ON
OFF
*Default setting.
