Copyright © 2006 CiDRA Corporation Page A-1
20675-01 Rev 02
Appendix A SONARtrac
TM
VF & GVF-100 SPECIFICATIONS
A1 Physical Specifications
A1.1 Power Supply
AC Voltage Version: 100 to 240 Volts AC, 50/60 Hz, 25 watts
DC Voltage Version: 18-36 Volts DC, 25 watts
A1.2 Fuse Protection
AC Voltage Version: The transmitter input power is fuse protected by
two 1 amp, 250 volt, 5mm x 20mm fuses.
DC Voltage Version: The transmitter input power is fuse protected by
two 3.15 amp, 250 volt, 5mm x 20mm fuses.
A1.3 Operating Temperature Range
Transmitter -4°F to +140°F (-20°C to +60°C)
Sensor Head Process Temperature -40°F to +212°F (-40°C to +100°C)
Sensor Head Ambient Temperature -40°F to +140°F (-40°C to +60°C)
A1.4 Storage Temperature Range
Transmitter -22°F to +176°F (-30°C to +80°C)
Sensor Head -40°F to +185°F (-40°C to +85°C)
A1.5 Construction Materials
•
Sensor Head
Fiberglass enclosure with PTFE gasket material for sizes 2 to 16 inch
Stainless steel enclosure with silicone end seals for sizes 18 inch and
above
•
Transmitter
Fiberglass enclosure with NEMA 4X rating.
Urethane gasket material.
Acrylic viewing window.
