Bottom Side View
1. Battery Lock/ Unlock Button
Battery cannot be moved when the button is positioned on lock status. Once the button is slid to
unlock position, the battery is removable.
2. Battery
Pack
This notebook will be powered by the battery pack when the AC/ DC adapter is disconnected.
3. Battery
Release
Button
It is a bounce-back device as a preparation for releasing the battery pack. Slide it with one hand
and pull the battery pack carefully with the other.
2
1
4
3
1. Battery Lock/ Unlock Button
2. Battery
Pack
3. Battery
Release
Button
4. Ventilator
