Rear side view – chiliGREEN MS1736 User Manual
Page 37
2-16
Intro
d
u
cti
ons
Rear Side View
1. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.
2. HDMI
Connector
HDMI (High Definition Multimedia Interface) is a new interface standard for PCs, displays
and consumer electronics devices that supports standard, enhanced and high-definition
video, plus multi-channel digital audio on a single cable.
5
3
1. Ventilator
2. HDMI
Connector
3. VGA
Port
4. USB
Port
5. RJ-45
Connector
6. ESATA
Port
7. Power
Connector
6
1
4
2
5
7
