7
Engl
ish
System Map: Front View with LCD Panel Open (Models B & C)
Note that the Touch-
pad and Buttons valid
operational area is that
indicated within the red
dotted lines above.
5
3
4
6
1
7
15.6” (39.62cm)
2
7
Figure 3
Front View with LCD Panel Open (Models B & C)
1. PC Camera (Optional)
2. LCD
3. Power Button
4. LED Status Indicators
5. Keyboard
6. Built-In Microphone
7. Touchpad & Buttons
4
6
3
5
7
1
2
17.3” (43.94cm)
Model B Model C
