2216 Controller
2
MC11 – 1.04
1
2216
–
D
ESCRIPTION
1.1
2216 Controller
The model 2216 controller is made by Eurotherm, and is fitted by Carbolite configured for
immediate use. It is a digital instrument with PID control algorithms. It is supplied as a sleeve
fitted controller.
The 2216 is supplied configured for easy use as a simple temperature controller, where on setting
the required temperature the controller immediately attempts to reach and maintain it.
A ramp-to-setpoint feature is available which may be used to limit the heating rate. This is shown
diagrammatically in figs 1 & 2.
The controller does not contain a real-time calendar, and is not subject to century-end date
problems.
