Cambridge SoundWorks Soundworks Radio 745 User Manual
Page 8
- -
PLAYER
POWER
OUTPUT
INPUT
AM
ANTENNA
FM ANTENNA
EXT
INT
INPUT
75 OHMS
PLAYER
INPUT
GETTING STARTED
Remove the SoundWorks Radio CD (See A) from its
protective polybag and place it in your preferred location.
The Radio CD’s Tone alarm sound and bass output will
be reduced if the Radio is placed on a compliant, soft
surface.
Connect the AM antenna (See B): To prepare the an-
tenna (1), fold the base (2) and snap it into place (3).
Position the AM antenna (4) in any out-of-the-way site,
preferably at least 8 inches apart from the Radio CD.
Insert the AM Antenna’s miniplug into the Radio CD’s rear
panel minijack marked AM ANTENNA (5).
Rotate the AM antenna to achieve the best signal for
individual AM stations.
A
B
1
2
3
4
5
ALARM
ST E RE O
C D IN
WIDE MO
NO
1
1
2
2
3
4
5
6
7
8
SNOOZE/MUTE
TRACK/TUNE
/ADJ
CD MODE
REPEAT
- FOLDER +
CD INFO
FOLDER
PRESETS
POWER
PLAYER
AUX
FM/AM
JOG
CD
SEEK
