CONTENTS
SECTION ITEM PAGE
1. INSTALLATION INSTRUCTIONS
2. LIGHTING INSTRUCTIONS
3. CLEANING INSTRUCTIONS
4. MAINTENANCE INSTRUCTIONS
7. WARRANTY
3
4
5
5
5
6
8
A Safety Precautions 3
B Unpacking Instructions 3
C Gas Connections
D Electric Installation (XSG model only) 4
E Leveling Adjustment 4
A Lighting Instructions 4
B Shutdown Instructions 5
3
5. WIRING DIAGRAM (XSG ONLY)
6. PARTS LIST & EXPLODED VIEW
XSG, XTG, XMG - 24 60,000 60,000
XSG, XTG, XMG - 36 90,000 90,000
XSG, XTG, XMG - 48 120,000 120,000
XSG, XTG, XMG - 60 150,000 150,000
XSG, XTG, XMG - 72 180,000 180,000
GAS SPECIFICATIONS
Propane Gas Natural Gas
BTU/HR @ 10” W.C. BTU/HR @ 3.5” W.C.
Model Number
XSG
This appliance will not operate during a power failure. No attempt
should bemadetooperate this gas appliance during power failure.
XTG
XMG
units are equipped with snap action thermostats and standing pilot systems. This griddle must have 115V, 60 Hz
electrical power to operate the main burners.
units are equipped with throttle type thermostat and standing pilot (no pilot safety provided)
units are equipped with manual gas valves, and standing pilot (no pilot safety provided). No griddle plate
temperature control is provided.
