Illustrations (continued) – Bakers Pride CO11-G Manual User Manual
Page 9
WHEEL PULLER BOLT 3/8”-HEX
BLOWER WHEEL
MOTOR
SET SCREW (2)
ASSEMBLY OF LEGS
(SHOWN WITH OPEN RACK STAND)
30” CONVECTION
OVEN LEGS
TOP LEFT
ANGLE
TOP RIGHT
ANGLE
1/2” FLATWASHER
(4 CORNERS ONLY)
1/2”-13 x 1”
HEX HEAD BOLT
(12 REQUIRED)
5/16”
FLATWASHER
(4 REQUIRED)
5/16”-18
HEX NUT
(4 REQUIRED)
OPEN RACK
SHELF
RACK
SUPPORT
3/8”-16 x 3/4”
TRUSS HEAD
SCREW
w/NUT & WASHER
(8 REQUIRED)
5. ILLUSTRATIONS (CONTINUED)
CONTROL PANEL
(ROTARY CONTROL)
SELECTOR
SWITCH
PILOT
LIGHT
(GREEN)
SELECTOR
SWITCH
THERMOSTAT
PILOT
LIGHT
(AMBER)
THERMOSTAT
LIGHTS
SWITCH
TIMER
STEAM
INJECTION
SWITCH
Figure 3
Figure 4
Figure 5
9
