4
Chapter 2
Using Billion ADSL Modem/Router
2.1 Cautions for Using Billion ADSL Modem/Router
Do not place the router under high humidity and high temperature.
Do not use the same power source for the device with other equipment.
Do not open or repair the case yourself. If the device is too hot, turn off the power
immediately and have a qualified serviceman repair it.
Place the product on the stable surface.
Only use the power adapter that comes with the package.
2.2 The Front LEDs
LED Meaning
1 PWR Lit green when power adapter is connected.
2 SYS When flash, it indicates that the device is working properly.
4 LNK Lit green when the LAN link is connected.
5 COL Flashes green when collision happens
7 ADSL
When lit, it indicates that the ADSL (Line) port is connected to the DSLAM
and working properly.
