KA Specifications
Performance
• Switching Differential:
Min: 10 in. - Max: 50 in.
(<10 in. or >50 in. consult factory)
• Maximum Pressure: 28 psi (2 bar)
Connectivity
• Cable: Up to 5 wires
Environmental
• Max. Liquid Temperature:
140ºF (>140ºF consult factory)
• Protection Rating:
IP67
NEMA 6
Certification
• CSA General Purpose
• CE
Electrical
• Maximum Voltage: 250 VAC or DC
• Maximum AC Current (Resistive): 6 A
• Maximum AC Current (Inductive): 3 A
• Maximum DC Power: 75 VA (0.3 A @ 250 V)
Physical
• Minimum Fluid Specific Gravity:
0.7 for Standard float
0.95 for Mini float
• Standard Cable Lengths:
5m (16 ft)
15m (49 ft)
• Weight: 0.75 lbs
• Float - Polypropylene
• Cable
PVC
Polyeurethane
Aton ® rubber
Teflon ® (PTFE)
TPU
APG
Automation Products Group, Inc. www.apgsensors.com
tel. 888.525.7300 [email protected]
2
2.25”
55 mm
6.1”
155 mm
6.70”
170 mm
4.0”
100 mm
Standard Series
5.1”
130 mm
3.0”
76 mm
M Series
