PG5 Specifications
Performance
• Accuracy (linearity & hysteresis):
±0.25% of full scale (BFSL)
±0.1% accuracy in selected ranges
• Stability – One Year Zero Drift: <±1% FS
• Thermal Zero Shift: ±0.02% FS/ ºF
• Thermal Sensitivity Shift: ±0.02% FS/ ºF
• Life: 10 million cycles minimum
• Adjustments: Auto zero, tare
Connectivity
• Output Options:
4-20 mA, 0-2 VDC, 0-5 VDC
Environmental
• Compensated Temp: 20
º - 130ºF (-7º - 54ºC)
• Storage Temp: -40
º - 160ºF (-40º - 71ºC)
• Operating Temp: 0
º - 160ºF (-18º - 71ºC)
Certification
• NIST certification on select ranges
• CE
Electrical
• Battery Option:
(1) Standard 9V (typical life 700 hrs)
Auto-off: 2 - 32 minutes
Low battery detection with 25% increments
• External Power Option: 9-28 VDC
• 6-Pin Connector: R04-R6M
Programming
• Programmable Features:
User selectable units of measure, Max/Min Reset
& Reading, Peak-Hold, Tare, Sample Rate, Range
Adjustment, Adjustable Resolution, Auto-Off
Physical
• Size: 2.66” x 1.55” (67.6 x 39.4 mm)
Connection: 1.25” (31.8 mm)
• Weight: 0.36 lb (163 grams)
• Injected molded case (EMI-X ® PDX-W-88341)
• Wetted Materials: 316L SS: up to 10,000 psi
• Display: 5 digit LCD, 0.4 in. digits
Automation Products Group, Inc.
www.apgsensors.com
tel. 888.525.7300
2
2.66”
67.6 mm
0.625
15.9
1/4” 18 NPT
1.25”
31.8 mm
1.55”
39.4 mm
6-Pin
Connector
HEX
