• Description
The HU (Hammer Union) pressure transmitter was designed for the rugged
environment of land-based and offshore drilling installations.
APG’s HU is an extremely rugged pressure transmitter. It is designed
specifically for use with the 1502 Hammer Wing Union. These units are
constructed from materials designed for service with highly abrasive and
corrosive media and comply with new NACE standards.
• Calibration Shunt Procedure
This design provides a true 20.0 mA calibration shunt output when 10 to 30
VDC is applied to the designated + Shunt Cal pin.
Ref. Wiring Diagram Document# 9002460
• Inspection and Maintenance
NOTE: No serviceable parts inside.
If the unit requires recalibration, or if the electrical connector needs to be
replaced, please contact the factory.
Electrical ratings; 10 to 30 Volts DC, 4 - 20 ma / 0-5VDC (per order)
Exia Class I Division 1; Groups C, D T4
Class I, Zone 0, AEx ia IIB T4
Ex ia IIB T4 (Ambient Temp. -40°C to 85°C) Type IP67
Vmax Ui= 30VDC, Imax Ii = 110ma, Pmax Pi = 1W, Ci = 60.89nF, Li = 10.95uH
The following approvals only apply to the L24 or 4-20mA version
ATEX Directive: 0334
Sira 13ATEX 2023
II 1G Ex ia IIB T4 Ga
-40°C
≤ Ta ≤ +85 °C
Ui
≤ 30 V, Ii ≤ 110 mA, Pi ≤ 1 W,
Ci
≤ 60.89 nF, Li ≤ 10.95 uH
IECEx CSA 13.0004
Ex ia IIB T4 Ga
Install in accourdance with drawing 9002460 (page 5).
All repairs and adjustments of the HU must be made by the factory. To modify,
disassemble, or alter the HU on site is strictly prohibited.
