PT-L9/L13/L14 Specifications
Performance
•
Accuracy
B.F.S.L. ≤ 0.25% of full scale
NIST up to ±0.1% available select ranges
• Temp Compensation Range: (Standard)
Up to 0º - 130ºF (-17º - 54ºC)
• Extended Temp Compensation Range: (Optional)
Up to -40º - 250ºF (-40º - 121ºC)
• Zero balance adjust: ±2% of full scale
Connectivity
• Output:
L9: 10 mV/V ±2%
L13: 3 mV/V ±2%
L14: 5 mV/V ±2%
Environmental
• Operating Temperature:
-40 º - 180ºF (-40º - 82ºC)
Electrical
• Input Impedance:
1200 minimum
• Output Impedance:
Approx. 1000 Ω
Physical
• Material: 15-5 or 316L SS
Automation Products Group, Inc. www.apgsensors.com
tel. 888.525.7300 [email protected]
2 7/31/2013
