Options
Part Number: IRU - 5 _____ - _____ - _____
A B C
APG
Automation Products Group, Inc. www.apgsensors.com
tel. 888.525.7300 [email protected]
3
A. Mounting
□ 41 1 in. NPT (Kynar T.F.)
□ 42 2 in. NPT (Kynar T.F.)
□ 32 2 in. sanitary ferrule (Kynar T.F.)
B. Output
□ 3 4-20 mA
□ 5 4-20 mA with 2 NPN outputs
□ 9 0-2.5V / 0-5V
IRU-5000 Accessories
Please order separately, by part number.
Description Part Number
Over Molded Extension Cables
with Foil Shield
4 Conductor
Straight, 2 m
135407-0002
Right Angle, 2 m 135407-1002
Straight, 5 m 135407-0005
Right Angle, 5 m 135407-1005
5 Conductor
Straight, 2 m
135415-0002
Right Angle, 2 m 135415-1002
Straight, 5 m 135415-0005
Right Angle, 5 m 135415-1005
Programming Module
RST-3001 (USB - 32 bit only) 125389
RST-3002 (USB - 32 and 64
bit compatible)
125389-1000
C. Cable/Microconnector
□ CL Cable (Specify L=length in feet) Standard 6 feet of cable
□ M Micro Connector
Wiring
2 1
4 3 5
IRU-5xx3-C
Red
+24 VDC
Black Ground
White mA+
IRU-5xx3-M
1 Brown
+24 VDC
2 White Not used
3 Blue Ground
4 Black mA+
5 Grey Not used
IRU-5xx9-C
Red
+24 VDC
Black Ground
White mA+
IRU-5xx5-C
Red
+24 VDC
Black Ground
Orange mA+
White NPN 1
Green NPN 2
IRU-5xx5-M
1 Brown
+24 VDC
2 White Not used
3 Blue Ground
4 Black mA+
5 Grey Not used
2 1
4 3 5
IRU-5xx9-M
1 Brown
+24 VDC
2 White Not used
3 Blue Ground
4 Black Voltage Out
5 Grey Not used
2 1
4 3 5
