Andrea Electronics SB-405W - Manual

C46-5458-2 Rev A
Package includes: one SuperBeam headset
with volume/mute control, USB audio adapter,
headset extension cable, travel case and one
instruction publication.
Congratulations on your
purchase of the Andrea
SuperBeam Computer Headset!
SB-405W
WARRANTY INFORMATION
Please visit our website at:
www.AndreaElectronics.com/
product_support.html
TROUBLESHOOTING
No sound from headset ear phone while
audio plays from computer.
Check all headset wire connections.
Check the volume control on inline module.
Windows Vista & Windows 7:
Right click on the tool tray speaker icon and
select playback devices.
Right click on the Andrea USB device and
enable it as the default playback audio device.
Check the tool tray speaker icon for proper
volume level adjustment and make sure the
speakers icon is not muted.
Double click on the Playback panel display of
AudioCommander to see what devices are
selected for audio playback
Mac:
Open the System Preferences panel.
Click on the Sounds icon.
Click on the Output button.
PHONES
HI DEFINITION USB “BOOM FREE” STEREO
HEADSET WITH ARRAY MICROPHONES AND 3D
SURROUND SOUND RECORDING
Connecting the SuperBeam USB headset
to your computer.
1. Plug the two 3.5mm stereo plugs
(Microphone/red and Speaker/green) from the
headset cable into the corresponding USB audio
adapter jacks. Note: make sure to match the
corresponding Microphone and Speaker icons
on the plug jackets to the markings on the USB
adapter.
2. Plug the USB connector into USB slot on
your computer.
3. Check the headset Vol/Mute control has Mic
Mute off and Volume Control is turned to max
position.
This product is covered by Andrea Electronics Corporation Patent No’s:
5,673,325 5,825,898 6,049,607 6,178,248 6,332,028 6,363,345 6,377,637
6,483,923 6,594,367 and patents pending
C46-5458-2 Rev-A
®
®
the default output audio device.
Adjust the volume slider for proper volume
level.
Make sure the Mute checkbox is not checked.
No sound is transmitted from the headset
microphone during communications or
recording on the computer.
Check all headset wire connections.
Check the microphone mute control is OFF on
inline module.
Windows:
Right click on the tool tray speaker icon and
select recording devices.
Double click on the Andrea USB device and
enable it as the preferred recording audio
device.
Check the AudioCommander recording volume
control for proper level adjustment.
Double click on the Record panel display of
AudioCommander to see what devices are
selected for audio input
Mac:
Open the System Preferences panel.
Click on the Sounds icon.
Click on the Andrea USB device to select it as
the default input audio device.
Adjust the volume slider for proper volume
level.
Your new SuperBeam headset is a Hi-Definition
USB stereo computer headset with “boom Free”
array microphones and new 3D surround sound
recording feature. The SuperBeam headset
provides revolutionary technology to enable a
more enjoyable computer audio experience
when listening to Music, watching Movies,
Internet Chatting (VoIP), Video Conferencing,
Gaming, Speech Recognition Dictating or
Recording audio/video in 3D Sound!
Attention! Download Andrea’s
user guide and free audio software
drivers to activate all the features of
your SuperBeam headset at:
http://www.andreaelectronics.com/
SuperBeam.html
If you do not have an internet connection,
please call Andrea Electronics customer service
at 1 (800) 442-7787 to request a user guide
and an audio software driver CD to be shipped
to you. TECHNICAL SERVICE
If you have questions, please visit our website
at: www.AndreaElectronics.com/product_
support.html or call our Technical Service Team
at 1-800-442-7787 (USA & Canada).
C46-5458 Rev A
CONNECTION OF THE SB-405 HEADSET TO YOUR COMPUTER
USB Port
EARPHONE VOLUME
CONTROL
MICROPHONE MUTE
RED PIN
(MIC)
GREEN PIN
(SPEAKER)
PLUGS CORRESPOND TO
JACK ICONS
PLACE HEADSET ON HEAD WITH
MICROPHONES FACING FORWARD OPHONES FA
MICROPHONE VOICE PICKUP DIRECTION
HEADBAND ADJUSTABLE AT THESE POINTS
Software Download
Attention! Download
Andrea’s user guide and free
audio software drivers to
activate all the features of your
SuperBeam headset at:
http://www.andreaelectronics.
com/SuperBeam.html
If you do not have an internet
connection, please call Andrea
Electronics customer service at 1
(800) 442-7787 to request a user
guide and an audio software driver
CD to be shipped to you.
