Section B 5
DR66 S ERVICE M ANUAL
ORDERING A DR66 UNIT
To order a new unit please specify the model number and AC mains voltage required.
MODEL DESCRIPTION ORDER CODE
DR66 6 inputs 6 outputs DR66/volts
ORDERING AN OPTION
To order an option please specify the model number.
DESCRIPTION ORDER CODE
DR128/66 DSPD delay expander card DR1-DSPD
DR66 DSP expander card DR66-DSPX
DR66 SYSNET option DR66-SNET
MANUALS, SOFTWARE AND SUPPORT DOCUMENTATION
DESCRIPTION ORDER CODE
DR66 User Guide AP3138
DR66 Service Manual AP3137
DR66 Brochure AP3205
DR66 WinDR Disk (1 of 3) 002-272
DR66 WinDR Disk (2 of 3) 002-273
DR66 WinDR Disk (3 of 3) 002-362
SERVICE TOOLS
The tools required to service the DR66 range of products are standard to an electronics service
workshop and are easily obtainable. The following items are necessary for disassembly and
service access:
1-point Crosshead screwdriver (M3, 4AB) AT0004
2-point Crosshead screwdriver (M4, 6AB) AT0002
5mm AF Nutdriver (D type mountings)
