GL2200 S ERVICE M ANUAL 6
Ordering a GL2200 Console
To order a new console please specify the model number and AC mains voltage required.
MODEL DESCRIPTION ORDER CODE
GL2200 12 Channel 10 mono + 2 stereo input channels GL2200-412/volts
GL2200 16 Channel 14 mono + 2 stereo inputs channels GL2200-416/volts
GL2200 24 Channel 22 mono + 2 stereo inputs channels GL2200-424/volts
GL2200 32 Channel 30 mono + 2 stereo inputs channels GL2200-432/volts
Ordering an Option
To order an option please specify the serial number of the console that is to have the option fitted.
MODEL DESCRIPTION ORDER CODE
GL2200-SL1 GL2200 SYS-LINK KIT GL2200-SL1
GL2200 Balanced Output IC option AE0302
RPS9 2U external linear power supply RPS9/volts
Manuals and Support Documentation
DESCRIPTION ORDER CODE
GL2200 User Guide AP3388
GL2200 Service Manual AP3389
GL2200 Brochure AP3390
GL2200 SYS-LINK Fitting Instructions AP3622
GL2200 SYS-LINK Application Note AP3623
RPS9 User Guide AP0334
Service Tools
The tools required to service the GL2200 are standard to an electronic service workshop and are
easily obtainable. The following items are necessary for disassembly and service access:
1-point Crosshead screwdriver (M3, 4AB) AT0004
2-point Crosshead screwdriver (M4, 6AB) AT0002
11mm AF Nutdriver (potentiometer nuts)
12mm AF Nutdriver (jack nuts)
