Allen&Heath GL4 USER GUIDE 1 User Manual
Page 3

A
LLEN
&
H
EATH
L
TD
GL4
M
ULTI
-F
UNCTION
L
IVE
C
ONSOLE
I
SSUE
:
1
M
UTE
G
ROUP
S
YSTEM
-
U
SER
M
ANUAL
P
AGE
:
34
C
ONTROL
S
ECTION
D
ISABLE
•
Turns off Mute Group
System when depressed
•
Mutes will still operate as
normal but Mute Groups &
MIDI will not
G
ROUPS
‘O
N
’
LED
•
If ON, shows that the Mute
Group System is enabled
•
Turns off when the D
ISABLED
switch is pressed down
G
ROUP
M
ODE
S
INGLE
M
ODE
Only one Mute Group can be active
at a time. Pressing a Mute Group will
turn off any previously selected
Mute Group
M
ULTI
M
ODE
More than one Mute Group can be
active at the same time
MIDI
S
LAVE
•
Used when linking 2 GL4s
using MIDI
MIDI
R
X
LED
•
Turns On when receiving
MIDI data
E
DIT
S
AFES
Safe Mutes can only be turned On or
Off by pressing them, they wont be
affected by Mute Groups or MIDI
•
Press to enter Edit Safes mode
•
Press the channel Mutes to make
them Safe
E
DIT
G
ROUPS
•
Press to enter Edit Group mode
•
Press a Mute Group switch to
select a Group for editing
•
Press channel Mutes to
add/remove them from the
selected Group
P
REVIEW
G
ROUPS
Preview mode allows you to view your
Groups on the channel Safe/Preview
LEDS
•
Press to enter Preview Group mode
•
Press a Mute Group switch to select
a Group for Previewing
8
M
UTE
G
ROUPS
Press a Mute Group switch to turn the
Group On and Off.
