WZ20S S ERVICE M ANUAL 7
ORDERING A SPARES KIT
It is recommended that the spares kit order code 002-491 is held and maintained by the service agent
to enable in-field service repairs to the WZ20S independent of the ALLEN & HEATH factory.
Commonly available items such as resistors, capacitors, tools and soldering equipment are not
included. The contents of the kit are listed below and are supplied in a cabinet of drawers. Individual
spare parts may be ordered. Please quote the description and order code for the part required.
DESCRIPTION ORDER CODE QTY
Fixings:
Screw M3 x 6mm TT Pan Pozi Black AB0071 10
Screw M3 x 8mm Pan Pozi Black AB0073 10
Screw M3 x 10mm Pan Pozi Black AB0076 10
Nylock Nut M3 AB0102 10
Screw M3 x 4mm Pan Pozi Black AB0233 10
Washer M3 Shakeproof AB0244 5
Screw 4AB x ¼ Pan Pozi Plated AB0252 1
Screw 4 x 5/16” Poly Pan Pozi Black AB2810 10
Screw M3 x 6mm TT CSK Pozi Black AB2929 5
Fastfoot AK0102 2
Knobs and caps:
Knob Red & Grey 11mm D AJ2074 10
Knob Blue & Grey 11mm D AJ2075 10
Knob Light Blue & Grey 11mm D AJ2076 10
Knob Green & Grey 11mm D AJ2077 5
Knob Dark Grey & Grey 11mm D AJ2078 10
Knob Yellow & Grey 11mm D AJ2079 10
Knob Brown & Grey 11m D AJ2080 5
Button 5.5mm Square Grey AJ2864 10
Button 10x5mm Rectangular Grey AJ2865 5
Button Round Black AJ2887 3
Button 5.5mm Square White AJ2960 10
Button 5.5mm Square Red AJ2961 10
Button 10 x 5mm Rectangular White AJ2962 10
Switch Cap Tall AJ8071 5
Fader Knob 11mm White+Black Line AJ8078 5
Fader Knob 11mm Yellow+Black Line AJ8080 5
Fader Knob 11mm Blue+Black Line AJ8081 10
Faders, Potentiometers, Switches and connectors:
Pot 20KK (203K 11mm wide) AI8003 10
Pot 20KB centre click (203B 11mm wide) AI8004 10
Pot 200KC x 2 (204C 1mm wide) AI8005 10
Pot 20KB x 2 centre click (14mm wide) AI8006 5
Pot 20KK x 2 (203K 14mm wide) AI8007 10
Pot 10KAC x2 (103AC 14mm wide) AI8008 10
Pot 5K (502RD 11mm wide) AI8111 5
Fader 10KD 100mm AI8117 5
Fader 10KD x 2 100mm AI8118 10
Switch 2PCO Latching 90° AL0162 5
Jack Socket Headphone AL0328 1
XLR 3 Pin Female Vertical PCB Mount AL2410 3
XLR 3 Pin Male Vertical PCB Mount AL2411 3
Phono Socket 24mm Dual Vertical PCB Mount AL3240 5
Jack Socket ¼” Stereo Unswitched AL3407 5
Jack Socket ¼” Stereo Switched AL3410 5
Switch 2PCO Latching Vertical AL8057 3
Switch 2PCO Latching 90Deg AL8065 5
Pot Nut 9mm AB8050 20
