4 3
Product may vary slightly from what is illustrated.
1. On indicator light
† 2. Bake/Broil temperature selector
(Part# CTO4300B-01)
(Part# CTO4300W-01)
† 3. Cooking FUNCTION selector
(Part# CTO4300B-02)
(Part# CTO4300W-01)
† 4. 60-minute TIMER/TOAST shade selector
(Part# CTO4300B-03)
(Part# CTO4300W-01)
† 5. Slide Rack
(Part# CTO4300B-07)
† 6. Slide-out crumb tray
(Part# CTO4300B-04)
7. Door handle
8. Rack slot
9. Extra-deep curved interior
† 10. Broil rack (Part# CTO4300B-05)
† 11. Bake pan/drip tray
(Part# CTO4300B-06)
†Consumer replaceable/removable parts
CONTROL PANEL
1. On indicator light
2. Temperature control
3. Cooking FUNCTION selector
4. 60-minute TIMER/TOAST shade selector
B
Important:
When making toast or using
the TIMER function, always
turn the dial past 20 and
then turn back or forward
to desired setting.
GROUNDED PLUG
As a safety feature, this product is equipped with a grounded plug, which will only
fit into a three-prong outlet. Do not attempt to defeat this safety feature. Improper
connection of the grounding conductor may result in the risk of electric shock. Consult
a qualified electrician if you are in doubt as to whether the outlet is properly grounded.
ELECTRICAL CORD
a) A short power-supply cord is to be provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord.
b) Longer extension cords are available and may be used if care is exercised in
their use.
c) If an extension cord is used,
1) The marked electrical rating of the cord set or extension cord should
be at least as great as the electrical rating of the appliance, and
2) The cord should be arranged so that it will not drape over the countertop
or tabletop where it can be pulled on by children or tripped over
unintentionally.
If the appliance is of the grounded type, the extension cord should
be a grounding-type 3-wire cord.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw to prevent removal
of the outer cover. To reduce the risk of fire or electric shock, do not attempt to
remove the outer cover. There are no user-serviceable parts inside. Repair should be
done only by authorized service personnel.
Note: If the power supply cord is damaged, it should be replaced by qualified
personnel or in Latin America by an authorized service center.
A















