9. Event
AirLive MD-720 User’s Manual 48
9.3 Motion Detection
Add the motion detection zone and name it. You can adjust the zone of detection with the
mouse. Maximum 10 detection zone can be set. The bar on the top of motion detection
area is red when the alarm is triggered.
z
Threshold: Set the threshold of the alarm in the motion detection zone. The
higher threshold is; the lesser detections can be triggered.
z
Sensitivity: Set the sensitivity for motion detection zone. The higher sensitivity is;
the more sensitive it gets.
9.4 Audio Detection
Select “on” if you want to activate the audio detection. The bar on the top of motion detection
area is red when alarm is triggered.
Threshold: Set alarm threshold for audio detection. The higher threshold is, the lesser
detections can be triggered.
Sensitivity: Set alarm sensitivity for audio detection. The higher sensitivity is, the more
sensitive it gets.
9.5 Tampering Detection
Select “on”, if you want to activate the tempering detection.
Trigger Duration: This setting is set for the trigger started for the duration of tampering
lasting you configure. The duration range is from 5 seconds to 900 seconds.
9.6 Schedule
The schedule is made for Event List to set the recording period. There are already 3
modes (Working Day、Weekend and Night Mode) has been set for a user. 7 more modes
are available to set manually.
