Ducati protocols
Channels received by SoloDL and EVO4 connected to Ducati Panigale protocol are:
ID CHANNEL NAME FUNCTION
ECU_1 ECU_RPM RPM
ECU_2 ECU_SPD_REAR Rear wheel speed
ECU_3 ECU_TPS1_ENG Throttle position cylinder 1
ECU_4 ECU_TPS2_ENG Throttle position cylinder 2
ECU_5 ECU_TPS_HAND Manual throttle
ECU_6 ECU_WATER_T Engine coolant temperature
ECU_7 ECU_SPD_FRONT Front wheel speed
ECU_8 ECU_INT_AIR_TEMP Intake air temperature
ECU_9 ECU_BATTERY Battery supply
ECU_10 ECU_BRAKE_SW Brake switch
ECU_11 ECU_CLUTCH_SW Clutch switch
ECU_12 ECU_GEAR Engaged gear
ECU_13 ECU_NEUTRAL_SW Neutral switch
ECU_14 ECU_OILP_SW Oil pressure switch
ECU_15 ECU_TURN_RIGHT Right turn indicator
ECU_16 ECU_TURN_LEFT Left turn indicator
ECU_17 ECU_SW_ENG_MAP Engine map selector
ECU_18 ECU_SW_BEAM High beam switch
ECU_19 ECU_BARO Barometric pressure
ECU_20 ECU_LAMB_H Horizontal cylinder lambda value
ECU_21 ECU_LAMB_TMP_H Horizontal cylinder lambda temperature
ECU_22 ECU_DIAG_H Horizontal cylinder lambda diagnosis
ECU_23 ECU_LAMB_V Vertical cylinder lambda value
ECU_24 ECU_LAMB_TEMP_V Vertical cylinder lambda temperature
