Industrial PCs OPC7008

General

data

External

dimensions:

256 x 192 x 66 mm 353 x 261 x 64 mm

413 x 290 x 68 mm

553 x 355 x 68 mm

Required

depth

clearance

for panel

integration

50mm 54mm

Match

dimensions

for panel

integration

240 x 176 mm

332 x 240 mm

392 x 269 mm

532 x 334 mm

Weight

Approx. 1.6 kg

Approx. 2.8 kg

Approx. 4.1 kg

Approx. 7.6 kg

Protection

class

IP 65 for the front

Max. switch-

on current:

7A (10ms)

Power

consumption
(without any

additional

load on any

of the USB

ports)

20W 35W 50W

75W

* Atom™ 1.6 GHz only
** Celeron® 1.2 GHz / Core™2 Duo 2.26 GHz only
*** All external USB interfaces can be disabled by software and in High Current version with up

to 1A

**** with Flash SSD, automotive hard disk or 2.5" industrial SSD only
¹ Allocation depends on software driver
² Tolerance +/– 1 mm
